DS800X Rally 2025 - 2026

At a Glance

Engine

798 cc Parallel Twin (KEL800 / Loncin LX284MW)

Category

Adventure Rally

Power

70 kW (93.8 HP) @ 9,000 rpm

Torque

81 N.m @ 6,500 rpm

ABS / TC

Switchable ABS + TCS

TFT Display

7" Full Color (TPMS)

Fuel Capacity

24 L

Engine Code

LX284MW (KEL800)

Cylinder Layout

Parallel twin, 19 deg cylinder offset, DOHC 8-valve

Bore x Stroke

84 x 72 mm

Compression Ratio

12:1

Spark Plug

NGK LMAR8J-9E (gap 0.9 mm)

Valve Clearance

Intake 0.15 - 0.20, Exhaust 0.20 - 0.25 mm (cold)

Engine Oil

SAE 10W-40, API SL+, JASO MA - 2.8 L with filter

Coolant

G48-spec OAT (1:1 with distilled water)

Transmission

6-speed, multi-plate wet clutch (hydraulic)

Primary Drive

1.816 ratio

Wet Weight

213 kg

Seat Height

850 mm

Wheelbase

1,576 mm

Ground Clearance

220 mm

Top Speed

190 km/h

Front Suspension

KYB USD, fully adjustable

Rear Suspension

KYB monoshock, multi-link

Suspension Travel

200 mm front / 190 mm rear

Brakes

NISSIN dual disc front, single rear

Wheels

Spoked 21" front / 18" rear

Tires

Pirelli (90/90-21 / 150/70-18)
