DS625X

2024 - 2026

Dual Sport / Adventure
Share
Power
63 HP / 47 kW
Peak torque
57 N·m
Weight
206 kg
Seat height
835 mm
Fuel
17.6 L No page cited

At a glance

A workshop value marked No page cited is not tied to a manual page on this site. Check it against the PDF under Manuals before you work from it. Performance and dimension figures carry no mark, since nothing is filled or torqued to them. Where a value names a manual, the name links to it. A row with a guide link has a written procedure under Service, with its own sources.

Performance

Category
Adventure Tourer
Power
63 HP / 47 kW @ 9,000 rpm (Euro V+ full power)
Torque
57 N·m @ 6,500 rpm
Top speed
183 km/h (full power) / 160 km/h (A2)
Fuel consumption
<= 4.8 L/100 km

Capacities & Fluids

Fuel capacity
17.6 L No page cited
Engine oil
SAE 10W-40 SL+ - 3.0 L No page cited Guide
Coolant
Ethylene glycol (-45 °C ice point), 2.0 L No page cited Guide

Engine

Engine
581 cc Parallel Twin (KEL600 / Loncin)
Engine code
KEL600
Cylinder layout
Parallel twin, DOHC 8-valve, water-cooled
Bore × stroke
76 × 64 mm
Compression
11.5:1
Spark plug
NGK CPR8EA-9 (gap 0.8 - 1.0 mm) No page cited
Valve clearance
Intake 0.10 - 0.15, Exhaust 0.15 - 0.20 mm (cold) No page cited Guide
Idle speed
1,300 ± 100 rpm
Fuel system
EFI
Emission standard
Euro V+

Transmission

Transmission
6-speed, multi-plate wet clutch
Primary drive
1.826 ratio
Final drive
2.867 ratio
Chain
520 SX, 114 links No page cited

Suspension & Chassis

Front suspension
Kayaba inverted fork, Ø 41 mm, 174 mm travel
Rear suspension
Central monoshock, 69.5 mm stroke, 181 mm travel

Brakes, Wheels & Tires

ABS / TC
2-channel ABS + TCS
Front brake
Dual 298 mm disc, 2-piston floating caliper
Rear brake
Single 240 mm disc, 1-piston floating caliper
Wheels
19" front (2.50) / 17" rear (4.25)
Tires
110/80R19 / 150/70R17 No page cited

Dimensions & Weight

Weight
206 kg (curb)
Seat height
835 mm
Wheelbase
1,465 mm
Ground clearance
220 mm
L × W × H
2,230 × 850 × 1,395 mm

Electronics & Equipment

TFT display
Color TFT (Voge Global App)
Riding modes
2

Trim & Pricing

A2 restricted variant
35 kW @ 10,000 rpm / 47 N·m @ 6,500 rpm
Colors
Desert Yellow, Black Knight
Warranty
2 years, unlimited mileage (extendable to 5)

Other

Rated output
Sources differ: the owner's manual (PDF page 87) lists 47 kW at 9,000 rpm and 57 N·m at 6,500 rpm. The KEL600 engine workshop manual (PDF page 7) lists 45 kW at 9,000 rpm and 55 N·m at 6,500 rpm. We cannot verify which figures are correct.

Also for this bike

Latest for DS625X

Features & equipment

Show all 24 features

Instrument panel

  • Connectivity (app pairing)
  • Fuel consumption
  • Fuel level
  • Gear indicator
  • Navigation
  • Outside temperature
  • Screen mirroring
  • LCD display (IPS)
  • Tire pressure (TPMS)
  • Voltage

Equipment

  • Adjustable windshield
  • Backlit switchgear
  • Center stand
  • Crash bars
  • Emergency brake signal (ESS)
  • Full LED lighting
  • Fog lights
  • Hand guards
  • HD front camera
  • Luggage rack
  • Spoked wheels
  • Switchable traction control (TCS)
  • USB outlet
  • 12v outlet

Troubleshooting

All troubleshooting

4 issues, most recently updated first, from owner and reviewer reports that Voge has not verified.

  • Harsh Rear Ride and Hard-to-Reach Rear Preload

    On the delivery settings the rear can feel harsh over sharp bumps. Backing off rear compression and adding rebound improved the ride on a Bennetts test bike.

    Reported Workaround Updated Years 2025 - 2026

  • DS625X Design Quirks (E5 Fuel, Front Brake, Legroom, Service Interval)

    Smaller points that reviewers raise about the DS625X. None of them stop the bike, but they are useful to know before you buy or set off.

    Reported Updated Years 2025 - 2026

  • Traction Control Cuts In Early and Feels Like Limp Mode

    Reviewers found the TCS cutting power at big lean angles before any slide and slow to give it back. A long press on the TCS button switches it off, and it comes back on at the next ignition.

    Reported Workaround Updated Years 2025 - 2026

  • Throttle Slack and Dead Zone at the Grip

    The DS625X uses a cable throttle, and test bikes have shown a large dead zone before the throttle opens. The manual gives a cable free play of 2-4 mm.

    Reported Workaround Updated Years 2025 - 2026
